Voyager 1 has left the Solar System. Will we ever overtake it?

Exiting the Solar System isn’t easy.

The Voyager spacecraft, illustrated here, are two of the five spacecraft currently on trajectories that will take them out of the Solar System. Both spacecraft actually left the heliosphere behind and entered interstellar space in the 2010s, and will, when Voyager 2 passes Pioneer 10 in 2023, become the two most distant spacecraft from Earth for the foreseeable future.

You must escape the Earth’s and Sun’s combined gravitational pulls.

The gravitational behavior of the Earth around the Sun is not due to an invisible gravitational pull, but is better described by the Earth falling freely through curved space dominated by the Sun. The shortest distance between two points isn’t a straight line, but rather a geodesic: a curved line that’s defined by the gravitational deformation of spacetime. The notion of “distance” and “time” is unique for every observer, but under Einstein’s description, all frames of reference are equally valid.

Of all the spacecraft ever launched, only five are on Solar System-departing trajectories.

There are five spacecraft presently either on their way out of the Solar System or that have already left it. From 1973-1998, Pioneer 10 was the most distant spacecraft from the Sun, but in 1998, Voyager 1 caught and passed it. In the future, Voyager 2 will pass it as well, and eventually New Horizons will pass Pioneer 11 and later Pioneer 10 as well. Modifications to gravity cannot predict deviations from the observed trajectories, which match the predictions of known physics with a non-modified General theory of Relativity.

The first, Pioneer 10, was launched a half-century ago.

The Pioneer 10 mission was launched with a number of instruments, and one of its science goals was to become the first spacecraft to visit and take data from Jupiter. Some of the first images of Jupiter from in situ are shown at right, showcasing a total solar eclipse shadow on Jupiter’s right side.

Humanity’s first spacecraft to encounter Jupiter, that gravitational assist accelerated it beyond escape velocity.

The most remarkable fact about Pioneer 10’s trajectory is that it gained nearly the maximum amount of velocity possible from a gravitational encounter with Jupiter. After becoming the first spacecraft to reach Jupiter in late 1973, it became the first spacecraft to achieve escape velocity in the Solar System. It remained our most distant spacecraft until 1998, when Voyager 1 surpassed it, and will fall to third place in 2023, when Voyager 2 overtakes it as well.

It remained our most distant probe until 1998, when Voyager 1 overtook it.

This illustration shows a Pioneer spacecraft on its way out of the Solar System, looking back at our Sun. The galactic plane is also visible. Although the Pioneer spacecraft are both now defunct, they will continue along their trajectory, influenced only by gravitation from hereon out.

Pioneer 11, launched in 1973, is also departing our Solar System.

Pioneer 11, following in the footsteps of Pioneer 10, actually flew through Jupiter’s lunar system, then used Jupiter’s gravity as an assist maneuver to take it to Saturn. While exploring the Saturnian system, a planetary science first, it discovered and then nearly collided with Saturn’s moon Epimetheus, missing it by an estimated ~4000 km. Newtonian gravity, alone, was capable of calculating these maneuvers.

Despite Jovian (1974) and Saturnian (1979) encounters, it’s our slowest outgoing spacecraft.

This graphic shows the relative positions of NASA’s most distant spacecraft as of 2011, where Voyager 1 was the most distant (it still is) but before it had left the heliosphere. In the time since, Voyager 2 has also left the heliosphere and has almost passed Pioneer 10 in terms of distance. New Horizons, which was only at Uranus’s orbital distance at the time (~20 AU) is now more than 150% farther (over 50 AU) from the Sun. It will someday pass both Pioneers, but will never pass either Voyager.

1977’s Voyager 1 is currently farthest from Earth: over 23 billion kilometers distant.

This illustration shows the position of NASA’s Voyager 1 and Voyager 2 probes, outside of the heliosphere, a protective bubble created by the Sun that extends well past the orbit of Pluto. Voyager 1 crossed the heliosphere’s boundary in 2012; Voyager 2 did the same in 2018. The asymmetric nature and extent of the bubble, particularly in the directions opposite the Voyager probes, have not been sufficiently quantified.

After entering interstellar space in 2012, it continually recedes ~17 km with each additional second.

This 1997 artwork shows the planets of the Solar System and the relative trajectories of the first four spacecraft on a course to exist the Solar System. In 1998, Voyager 1 overtook Pioneer 10, and in 2012, it passed the heliopause and entered interstellar space. Voyager 2 entered interstellar space in 2018 and won’t pass Pioneer 10 until 2023; therefore we strongly suspect that Pioneer 10 is in interstellar space as well, but it is no longer functional.

Voyager 2, also launched in 1977, slightly trails Voyager 1.

Voyager 2 famously conducted a “grand tour” of the Solar System, closely flying by each of the four gas giants and imaging their planetary, lunar, and ringed systems. In order to accomplish it, Voyager 2 was launched on an initially slower trajectory than Voyager 1. Despite being launched first, it’s less far and less fast than its twin counterpart.

After encountering all four gas giants, it entered interstellar space in 2018.

At the end of 2018, the cosmic ray subsystem aboard NASA’s Voyager 2 spacecraft provided evidence that Voyager 2 had left the heliosphere. There were steep drops in the rate of heliospheric particles that hit the instrument’s radiation detector, and significant increases in the rate of cosmic rays.

2006’s New Horizons became the fastest spacecraft ever launched.

Just 15 minutes after passing by Pluto on July 14, 2015, the New Horizons spacecraft snapped this image looking back at the faint crescent of Pluto illuminated by the Sun. The icy features, including multiple layers of atmospheric hazes, are breathtaking. As Pluto rotates on its axis and ventures closer-and-farther from the Sun, certain volatiles can vaporize and condense, leading to various forms of precipitation, such as nitrogen and methane.

Despite a boost/redirect by Jupiter while journeying to Pluto, it won’t catch either Voyager.

The New Horizons spacecraft, launched in 2006 with the fastest launch speed of any spacecraft, was slightly boosted but mostly redirected onto a trajectory that would lead to a close fly-by encounter with Pluto. The lack of a major gravity assist means that its speed will never allow it to catch up to either Voyager 1 or 2.

Voyager 2 will surpass Pioneer 10 in 2023; New Horizons will overtake both Pioneers next century.

Although Pioneer 10 was the first launched spacecraft, in 1972, with a trajectory that would take it out of the Solar System, it was surpassed by Voyager 1 in 1998 and will be surpassed by Voyager 2 in 2023 and New Horizons in the late 2100s. No other mission ever launched is slated to overtake Voyager 1, which is currently both the farthest and fastest-moving human-created spacecraft.

A 2098 encounter with Jupiter will cause now-defunct Ulysses to escape.

The Ulysses spacecraft, launched in 1990, was designed to orbit the Sun and study it at all latitudes, from a variety of near-and-far distances. A 2098 gravitational encounter with Jupiter is coming, which will impart a gravitational kick sufficient to send Ulysses out of the Solar System.

Without a superior mission, Voyager 1 will remain humanity’s most distant spacecraft.

A logarithmic chart of distances, showing Voyager, our Solar System, the Oort Cloud, and our nearest star: Proxima Centauri. In jumps of factors of 10, we go from Earth’s orbit to Saturn’s orbit to Voyager 1’s distance to the inner Oort cloud to the middle of the Oort cloud to more than a light-year away. Stars and other masses move through the galaxy over time, and routinely pass within the Oort cloud.
