One of the nearest, brightest stars to us, Fomalhaut , is a remarkable system.
The dust ring around the bright star, Fomalhaut, is shown in ALMA data in orange and from older Hubble Space Telescope data in blue. Even though these observatories differ in wavelength sensitivity by a factor of ~1000, they can both reveal the same dusty ring that’s the analogue of our Kuiper belt.
Credits : ALMA (ESO/NAOJ/NRAO) and NASA/ESA Hubble Space Telescope
Only a few hundred million years old, it’s incredibly dusty.
Long after the planet-forming gas from a protoplanetary system is blown away, large quantities of dusty debris can persist, bombarding the young planetary system for several hundreds of millions of years. This happened in our early Solar System for about ~600 million years, and is still potentially happening around stars such as Vega, Fomalhaut, and Epsilon Eridani.
Credit : NASA/Dana Berry
No surefire planets were seen.
This animation shows the four super-Jupiter planets directly imaged in orbit around the star HR 8799, whose light is blocked by a coronagraph. The four exoplanets shown here are among the easiest to directly image owing to their large size and brightness, as well as their huge separation from their parent star. No such surefire planetary signal has been revealed around Fomalhaut.
Credit : Jason Wang (Northwestern)/William Thompson (UVic)/Christian Marois (NRC Herzberg)/Quinn Konopacky (UCSD)
This impact-rich system likely undergoes heavy bombardment.
Artist’s concept of meteors impacting ancient Earth. Some scientists think such impacts may have delivered water, amino acids, and other molecules useful to emerging life on Earth, as the evidence is strong that the impact and cratering rate across the Solar System was much higher than present for the first 0.4-0.7 billion years of our Solar System’s history.
Credit : NASA’s Goddard Space Flight Center Conceptual Image Lab
Earlier Hubble observations revealed a ring with an interior “bright spot.”
In 2008, when the early Hubble observations showed the bright point of light interior to Fomalhaut’s great dust ring, many leapt to the conclusion that this bright, interior object was a shepherding planet orbiting Fomalhaut. This is no longer a viable explanation for the data.
Credit : NASA, ESA, and A. Feild (STScI)
Originally a planetary candidate , follow-up observations showed peculiar motions and dimming.
Although early Hubble observations of Fomalhaut indicated not only a Kuiper belt-like ring around it, but a possible planet, dubbed Fomalhaut b, interior to that ring, follow-up observations have shown this to more likely be an expanding, fading, transient dust cloud.
Credit : NASA, ESA, and A. Gáspár and G. Rieke (University of Arizona)
One explanation was an expanding, fading dust cloud.
This animation shows the Bok globule Barnard 68 in a variety of visible and infrared wavelengths. As the longer wavelengths reveal, this is not a hole in the Universe but simply a dusty cloud of gas, where the longer wavelengths of light penetrate and pass through the dust. As dust clouds form and dissipate, the dust density can be revealed by examining the light blocked and transmitted by fixed, background objects.
Credit : ESO
However, new JWST observations revealed unprecedented details within Fomalhaut.
These three images show the Fomalhaut system as observed by JWST at wavelengths of 15.5, 23.0, and 25.5 microns, respectively. The 23.0 micron observations were made with a coronagraph, while the inner disk is revealed at 15.5 microns. The bottom row shows these images “stretched” to illustrate their true size as they would appear if viewed face-on.
Credit : NASA, ESA, CSA, A. Gáspár (University of Arizona) et al., Nature Astronomy, 2023
Both Kuiper belt and asteroid belt analogues were seen, along with an intermediate belt.
The structure of the Fomalhaut stellar system is revealed for the first time in this annotated JWST image. A central inner disk, followed by a (likely planet-caused) gap, an intermediate belt, more planets (and another gap), and finally a Kuiper belt analog, complete with what’s been dubbed the “great dust cloud” newly forming inside, are all revealed.
Credit : NASA, ESA, CSA, A. Gáspár (University of Arizona) et al., Nature Astronomy, 2023
A novel bright, dusty feature also appeared , elsewhere than the now-faded old bright spot.
Dust grains come in a variety of sizes and compositions, and can form in the aftermath of an energetic collision. As the material expands and cools, dust forms, gets heated, and re-radiates that heat in the infrared, enabling telescopes like JWST to detect its presence. But we must be careful; other, more distant features can mimic dust in this regard.
Credit : E.K. Jessberger et al., in Interplanetary Dust, 2001
Called the “Great Dust Cloud” by JWST scientists , it suggested an independent, dust-generating impact.
A wide variety of telescopes have looked at the Fomalhaut system in a variety of wavelengths from both the ground and in space. Only JWST, so far, has been able to resolve the inner regions of the dusty debris present in the Fomalhaut system.
Credit : NASA, ESA, CSA, A. Gáspár (University of Arizona) et al., Nature Astronomy, 2023
But long-term, multiwavelength observations pointed to another explanation .
7 candidate objects in the Fomalhaut field-of-view were revealed by the Keck telescopes in a 2013 study. All 7 identified objects were inconsistent with a planet-like explanation, and instead appeared to be background objects.
Credit : T. Currie et al., ApJL, 2013
Perhaps it’s always been the same light source : a more distant, serendipitously aligned background object.
As Earth orbits the Sun and nearby stars migrate across the sky, a helix-shaped motion appears to emerge. As different background objects remain relatively fixed with respect to Earth, the foreground star system, Fomalhaut in this case, sees these background objects shift relative to it. If the foreground system is dusty, these background objects will have differing amounts of light absorbed and transmitted over time.
Credit : T. Currie et al., ApJL, 2013
As nearby Fomalhaut moves across the sky, background objects appear to shift position.
Multiple background objects, circled in the images here, can be seen using ALMA, Keck, and JWST in the field-of-view of Fomalhaut. With greater sensitivity comes a greater probability of revealing background objects, in addition to faint objects within the foreground (Fomalhaut) system.
Credit : G.M. Kennedy et al., MNRAS submitted, 2023
Intervening dust causes background light to irregularly scatter and be absorbed.
The offset between bright spots in the Fomalhaut system as seen by ALMA (whose names start with “A”) and Keck (whose names start with “K”) provide evidence that they are background objects, with the Fomalhaut system moving relative to them. Because the ground-based data were obtained 6-to-18 years prior to the JWST data, they are unlikely to be common proper motion companions to Fomalhaut.
Credit : G.M. Kennedy et al., MNRAS submitted, 2023
JWST’s mid-infrared eyes are sharp and sensitive enough to reveal background stars and galaxies through Fomalhaut’s dust.
The stellar streams being ripped from one of the interacting member galaxies of Stephan’s Quintet glitters in this image, but even more spectacular are the rich selection of background galaxies that can be seen in glorious detail behind the nearby foreground objects. With JWST’s unprecedented capabilities, “background galaxies” are at risk of contaminating foreground systems that we attempt to image in great detail with JWST: something that’s been known since the first JWST science release.
Credit : NASA, ESA, CSA, and STScI
Earlier observations support the “background object” explanation .
The offset between the bright point sources that ALMA observed previously (circles, with “A” as a prefix) versus what JWST observed (color-coded data) show an offset in position between the bright spots seen. This is a potential indication that these are background objects, which the spectrum of “A02” also supports.
Credit : G.M. Kennedy et al., MNRAS submitted, 2023
JWST’s unprecedented capabilities, sadly, bring novel, confounding sources of error.
This three-observatory view of the debris disk around Fomalhaut was constructed by Adam Block with Hubble, ALMA, and JWST data. The three dusty areas correspond to an inner disk, an intermediate belt, and a Kuiper-like belt, with planets likely persisting in the gaps. Many of these features were unexpected, but bright point sources seen in these images may indicate background objects, rather than point-like features within the system itself.
Credit : Adam Block/Andras Gaspar/Steward Observatory/University of Arizona
Mostly Mute Monday tells an astronomical story in images, visuals, and no more than 200 words. Talk less; smile more.
